The JW5211 is a current mode monolithic buck switching regulator. Operating with an input range of 2.5V-6V, the JW5211 delivers 1.2A of continuous output current with integrated P-Channel and N-Channel MOSFETs. The internal synchronous power switches provide high efficiency. At light loads, the regulator operates in low frequency to maintain high efficiency. Current mode control provides tight load transient response and cycle-by-cycle current limit.

The JW5211 guarantees robustness with hiccup output short-circuit protection, FB short-circuit protection, current run-away protection, input under voltage lockout, hot-plug protection, and thermal protection.

FEATURES


2.5V to 6V operating input range


Up to 1.2A output current


Up to 95% peak efficiency


High efficiency (>85%) at light load


Internal Soft-Start


1.5MHz switching frequency


Input under voltage lockout


Hot-plug protection


Short circuit protection


Thermal protection


Available in SOT23-5 and SOT23-6package

APPLICATIONS


5V or 3.3V Point of Load Conversion


Set Top Boxes


Telecom/Networking Systems


Storage Equipment


GPU/DDR Power Supply
