The JW5018B is a current mode monolithic buck switching regulator. Operating with an input range of 4.7V~40V, the JW5018B delivers 600mA of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, the regulator operates in low frequency to maintain high efficiency and low output ripple. Current mode control provides tight load transient response and cycle-by-cycle current limit.

The JW5018B guarantees robustness with short-circuit protection, thermal protection, current run-away protection, and input under voltage lockout.

The JW5018B is available in 6-pin SOT23-6 package, which provides a compact solution with minimal external components.

FEATURES


4.7V to 40V operating input range

600mA output current


Up to 93% efficiency


High efficiency (>78%) at light load


Internal Soft-Start


800kHz switching frequency


Input under voltage lockout


Available in SOT23-6 package


Current run-away protection


Short circuit protection


Thermal protection

APPLICATIONS


Distributed Power Systems


Automotive Systems


High Voltage Power Conversion


Industrial Power Systems


Battery Powered Systems
