The JW1121A is a current mode monolithic buck LED driver. Operating with an input range of 4.2V-20V, JW1121A delivers 1.5A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. It incorporates analog dimming mode and PWM signal to analogy dimming mode onto a single control pin.

The JW1121A guarantees robustness with LED short protection, thermal protection, start-up current run-away protection, input under voltage lockout.

The JW1121A is available in 6-pin SOT23 packages, which provide a compact solution with minimal external components.

FEATURES


4.2V to 20V operating input range

1.5A output current


Up to 94% efficiency

@ Vin=12V, Vout=6V


1MHz Switching frequency


PWM to Analog dimming mode


Input under voltage lockout


Start-up current run-away protection


LED short protection


Thermal protection


Available in SOT23-6 packages

APPLICATIONS


IP camera and CCD camera


Flash light


Display cabinet lamp


LED Sign
