The JW5062T is a monolithic buck switching regulator based on I2 architecture for fast transient response. Operating with an input range of 4V~18V, JW5062T delivers 4A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, the regulator operates in low frequency to maintain high efficiency and low output ripples.

JW5062T guarantees robustness with output short protection, thermal protection, current run-away protection, input under voltage lockout, and FB short protection.

JW5062T is available in TSOT23-6 package, which provide a compact solution with minimal external components.

FEATURES


4V to 18V operating input range

4Aoutput current


Up to 95% efficiency


High efficiency (>85%) at light load


600kHz switching frequency


Internal soft-start


Input under voltage lockout


Feedback short protection


Current run-away protection


Output short protection


Thermal protection


Available in TSOT23-6package

APPLICATIONS


Distributed Power Systems


Networking Systems


FPGA, DSP, ASIC Power Supplies


Green Electronics/ Appliances


Notebook Computers
