The JW5231 is a current mode monolithic buck switching regulator. Operating with an input range of 2.5V-5.5V, the JW5231 delivers 1.5A of continuous output current with integrated P-Channel and N-Channel MOSFETs. The internal synchronous power switches provide high efficiency. Current mode control provides tight load transient response and cycle-by-cycle current limit.

The JW5231 guarantees robustness with hiccup output short-circuit protection, FB short-circuit protection, start-up current run-away protection, input under voltage lockout protection, hot-plug in protection, and thermal protection.

FEATURES


2.5V to 5.5V operating input range


Up to 1.5A output current


Up to 94% peak efficiency


Internal Soft-Start


1.5MHz switching frequency


Input under voltage lockout


Short circuit protection


Thermal protection


Hot-plug in protection


Output POK indication (available in SOT23-6

package)


Available in SOT23-5/SOT23-6 package

APPLICATIONS


5V or 3.3V Point of Load Conversion


Set Top Boxes


Telecom/Networking Systems


Storage Equipment


GPU/DDR Power Supply
