华邦(Winbond)

  Winbond SDRAM/DDR 系列产品特点:

•高速度— 1600Mbps的DDR3能迎合需要高速效的数码电视、STB、蓝光播放机和网络设备;

•低功耗 —DDR3(1.5V) 的电压比DDR2(1.8V)低,能减低系统的耗电量;

•工作温度范围宽 - 最新的Q版本工作温度在-40 to +105;

•高品质 - 由于是国内生产与加工,无形中降低了很多成本。广泛应用于数码类以及消费类电子产品中;

•产线长 - Winbond已拥有全系列的DRAM产品。其中以TSOP-II和FBGA封装的128Mb~256Mb SDRAM、128Mb~512Mb DDR。



Winbond SDRAM系列规格参数
Part No. Density Organization Speed Grade Max Freq Voltage Package
W9816G6IB 16M 1Mx16 -6 166 MHz 3.3V±0.3V Packaged in VFBGA 60 balls pitch=0.65mm, using Lead free materials with RoHS compliant
-7 143 MHz 2.7V~3.6V
W9816G6IH 16M 1Mx16 -5 143 MHz 3.3V±0.3V Package in 50-pin, 400 mil TSOP II, using Lead free materials with RoHS compliant
200 MHz
-6/-6I/-6A 166 MHz 3.3V±0.3V
-7/-7I 143 MHz 2.7V~3.6V
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade Max Freq Voltage Package
W9864G2IH 64M 2Mx32 -5 200 MHz 3.3V±0.3V Packaged in TSOP II 86-pin, using Lead free materials with RoHS compliant
-6/-6I/-6A 166 MHz
-7 143 MHz 2.7V~3.6V
W9864G6IH 64M 4Mx16 -5 200 MHz 3.3V±0.3V Packaged in TSOP II 54-pin, 400 mil using Lead free materials with RoHS compliant
-6/-6I/-6A 166 MHz
-7/-7S 143 MHz 2.7V~3.6V
W9864G6JH 64M 4Mx16 -5 200 MHz 3.3V±0.3V Packaged in TSOP II 54-pin, 400 mil using Lead free materials with RoHS compliant
-6/-6I 166 MHz
-7/-7S 143 MHz 2.7V~3.6V
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life, N= None for new design.

Part No. Density Organization Speed Grade Max Freq Voltage Package
W9812G2IH 128M 4Mx32 -6C 166 MHz 3.3V±0.3V Packaged in TSOP II 86-pin, using Lead free materials with RoHS compliant
-6/-6I/-6A 2.7V~3.6V
-75 133 MHz
W9812G2IB 128M 4Mx32 -6/-6I/-6A 166 MHz 2.7V~3.6V Packaged in TFBGA 90 Ball(8x13mm2 ), using Lead free materials with RoHS compliant
-75 133 MHz
W9812G6IH 128M 8Mx16 -5 200 MHz 3.3V±0.3V TSOP II 54-pin, 400 mil using Lead free materials with RoHS compliant
-6/-6C/-6I/-6A 166 MHz
-75 133 MHz
W9812G6JH 128M 8Mx16 -5 200 MHz 3.3V±0.3V TSOP II 54-pin, 400 mil using Lead free with RoHS compliant
-6/-6I 166 MHz
-75 133 MHz
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade Max Freq Voltage Package
W9825G2DB 256M 8Mx32 -6 166 MHz 3.3V±0.3V TFBGA 90 ball using Pb free with RoHS compliant
-6I 2.7V~3.6V
-75/75I 133 MHz
W9825G6EH 256M 16Mx16 -5 200MHz 3.3V±0.3V Packaged in TSOP II 54-pin, 400 mil - 0.80, using Lead free materials with RoHS compliant
-6/-6I/-6A 166 MHz
-6 133 MHz
-75/75I/75A
W9825G6JH 256M 16Mx16 -5 200MHz 3.3V±0.3V Packaged in TSOP II 54-pin, 400 mil - 0.80, using Lead free materials with RoHS compliant
-6/-6I 166 MHz
-6 133 MHz
-75
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Winbond DDR/DDR1系列规格参数
Part No. Density Organization Speed Grade
W9464G6IH 64Mb DDR 4Mx16 4 Banks -4 250 MHz CL3/CL4
-5/-5I 200 MHz CL3
-6/-6I 166 MHz CL2.5
W9464G6JH 64Mb DDR 4Mx16 4 Banks -4 250 MHz CL3/CL4
-5 200 MHz CL3
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life, N=Not recommended for new design.

Part No. Density Organization Speed Grade
W9412G6IH 128Mb DDR  8Mx16 4 Banks -4 250 MHz CL3/CL4
-5/-5I 200 MHz CL3
-6/-6I 166 MHz CL2.5
W9412G6JH 128Mb DDR  8Mx16 4 Banks -4 250 MHz CL3/CL4
-5 200 MHz CL3
W9412G2IB 128Mb DDR  4Mx32 4 Banks -4 250 MHz CL3/CL4
-5/-5I 200 MHz CL3
-6/-6I 166 MHz CL2.5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life, N=Not recommended for new design.

Part No. Density Organization Speed Grade
W9712G6JB 256Mb DDR 8Mx16 4 Banks -18 DDR2-1066 2007/7/7
-25/ 25I/25A DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
W9712G8JB 256Mb DDR 16Mx8 4 Banks -18 DDR2-1066 2007/7/7
-25 DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade
W9712G6JB 128Mb DDR2     8Mx16 4 Banks -18 DDR2-1066 2007/7/7
-25/ 25I/25A DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
W9712G8JB 128Mb DDR2     16Mx8 4 Banks -18 DDR2-1066 2007/7/7
-25 DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade CL-tRCD-tRP?
W9725G6JB 256Mb DDR2 16Mx16 4 Banks -18 DDR2-1066 2007/7/7
-25/ 25I/25A DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
W9725G8JB 256Mb DDR2 32Mx8 4 Banks -18 DDR2-1066 2007/7/7
-25/ 25I DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade CL-tRCD-tRP?
W9751G6JB 512Mb DDR2 32Mx16 4 Banks -18 DDR2-1066 2007/7/7
-25/25I DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
W9751G8JB 512Mb DDR2 64Mx8 4 Banks -18 DDR2-1066 2007/7/7
-25/25I DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade CL-tRCD-tRP?
W971GG6JB 1G DDR2 64Mx16 8 Banks -18 DDR2-1066 2006/6/6
-25/25I DDR2-800 2005/5/5
-3 DDR2-667 2005/5/5
W971GG8JB 1G DDR2 128Mx8 8 Banks -18 DDR2-1066 2006/6/6
-25/25I DDR2-800 2005/5/5
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.

Part No. Density Organization Speed Grade CL-tRCD-tRP?
W972GG6JB 2G DDR2 128Mx16 8 Banks -18 DDR2-1066 2007/7/7
-25/25I DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
W972GG8JB 2G DDR2 256Mx8 8 Banks -18 DDR2-1066 2007/7/7
-25/25I DDR2-800 5-5-5/6-6-6
-3 DDR2-667 2005/5/5
* Status: P= Mass Production, S=Samples, UD=Under Development, UD (Time)= Under Development(Ready Time), EOL=End of life.
