The MT3222 are dual 1.5MHz,2.5A constant on-time(COT)controlled synchronous step-down converters.MT3222 consumes extremely low 38µA quiescent current hence achieves superior light load efficiency.The 2.5V to 6V input supply range makes the parts ideally suited for single Li-Ion applications.100%duty cycle capability provides low dropout operation,which extends operating time in battery-operated systems.The constant on-time control scheme simplifies loop compensation and offers excellent load transient response.The high gain error amplifier in the control loop provides excellent load and line regulation.Proprietary adaptive on-time helps MT3222 to achieve nearly constant switching frequency across the continuous conduction load range.MT3222 has cycle-by-cycle current limit and hiccup mode to protect over-load or short circuit fault conditions.The MT3222 is available in an 8-pin TSOT23 package.





　　FEATURES



　　-Dual Outputs operating independently with



　　2x2.5A Output Current Capability



　　-Wide Input Range from 2.5V to 6V



　　-Adjustable Output Voltages from 0.6V to VIN



　　-Up to 95%High Efficiency



　　-Proprietary Fast Transient Constant On Time



　　Architecture Stable with low ESR Ceramic Output



　　Capacitors



　　-1.5%0.6V Feedback Voltage



　　-1.5MHz Switching Frequency



　　-38µA Low Quiescent Current



　　-100%Duty Cycle Operation



　　-RDSON 65mΩHS/35mΩLS VIN=5V



　　-Internal 1.5msec Soft-Start



　　-Cycle-by-cycle Current Limit Protection



　　-Over-Load and Short Circuit Hiccup Mode



　　-Output Discharging in Shutdown



　　-Thermal Shutdown Protection



　　-Available in a TSOT23_8L Package



　　-Pb-Free RoHS Compliant



　　APPLICATIONS



　　-Solid-State and Hard Disk Drives



　　-USB TypeC Dock Station



　　-Smart Phone and Tablets



　　-WiFi RF Moudules
