The TP128X family amplifiers are the newest high supply voltage amplifiers with low offset,low power,and stable high-frequency response.They incorporate 3PEAK’s proprietary and patented design techniques to achieve very good AC performance with 7MHz bandwidth,20 V/μs slew rate,and low distortion while drawing only 1600μA of quiescent current per amplifier.The input common-mode voltage range extends to V–,and the outputs swing rail-to-rail.The TP128X family can be used as plug-in replacements for many commercially available opamps to reduce power and improve input/output range and performance.The TP128X has an over-temperature protection feature to guarantee chip safety.The output of TP128X will enter high impendence when the die temperature reaches around 170°C and will recover the function when the die temperature is down to around 150°C.

Features

-Supply Voltage:4.5 V to 36 V

-Offset Voltage:±150μV Maximum

-Differential Input Voltage Range to Supply Rail,can Work as Comparator

-Input Rail to–VS,Rail to Rail Output

-Bandwidth:7 MHz

-Slew Rate:20 V/μs

-Excellent EMI Suppress Performance:45 dB at 1GHz

-Over-Temperature Protection

-Low Noise:25 nV/√Hz at 1kHz

-4 kV HBM,2 kV CDM,400 mA Latch Up

-–40°C to 125°C Operation Temperature Range

Applications

-Instrumentation

-Active Filters,ASIC Input or Output Amplifier

-Sensor Interface

-Motor Control

-Industrial Control
