The TP124X series amplifiers are newest high supply voltage amplifiers with low offset,low power and stable high frequency response.They incorporate 3PEAK’s proprietary and patented design techniques to achieve very good AC performance with 1MHz bandwidth,0.7V/μs slew rate and low distortion while drawing only 150μA of quiescent current per amplifier.The input common-mode voltage range extends to V–,and the outputs swing rail-to-rail.The TP124X family can be used as plug-in replacements for many commercially available op-amps to reduce power and improve input/output range and performance.The combination of features makes the TP124X ideal choices for industrial control,instrumentation.

Features

-Supply Voltage:4.5V to 36V

-Offset Voltage:±300μV Maximum

-Differential Input Voltage Range to Supply Rail,can Work

as Comparator

-Input Rail to–VS,Rail to Rail Output

-Bandwidth:1 MHz

-Slew Rate:0.7V/μs

-Excellent EMI Suppress Performance:80dB at 1GHz

-Offset Voltage Temperature Drift:2μV/°C

-Low Noise:30 nV/√Hz at 1kHz

-2KV HBM,1KV CDM

-–40°C to 125°C Operation Temperature Range

Applications

-Instrumentation

-Active Filters,ASIC Input or Output Amplifier

-Sensor Interface

-Industrial Contro
