The TPA186X series amplifiers are the newest high supply voltage amplifiers with 30μV low offset,low noise,and stable high-frequency response.They incorporate 3PEAK’s proprietary and patented design techniques to achieve excellent AC performance with 6 MHz bandwidth,5 V/μs slew rate,and low distortion while drawing only 1.4 mA quiescent current per amplifier.The input common-mode voltage range extends to V–,and the outputs swing rail-to-rail.The TPA186X has an over-temperature protection feature to guarantee chip safety.The output of TPA186X will enter high impendence when the die temperature reaches around 170°C and will recover the function when the die temperature is down to around 150°C.The product has a very small power temperature coefficient,which is helpful for temperature-sensitive applications.

Features

-Supply Voltage:4.5 V to 40 V

-Offset Voltage:±30μV Maximum

-Differential Input Voltage Range to Supply Rail,can Work as Comparator

-Input Rail to–VS,Rail to Rail Output

-Drive Any Capacitive Load

-Bandwidth:6 MHz,Slew Rate:5 V/μs

-Excellent EMI Suppress Performance:85 dB at 1GHz

-Over-Temperature Protection

-Low Noise:8 nV/√Hz at 1 kHz

-2 kV HBM,1 kV CDM,500 mA Latch Up

-–40°C to 125°C Operation Temperature Range

Applications

-Instrumentation

-Active Filters,ASIC Input or Output Amplifier

-Sensor Interface

-Motor Control

-Industrial Control
