TP258X系列放大器是最新的高电源电压放大器，具有低偏移、低功率和稳定的高频响应。它们结合了3PEAK的专有和专利设计技术，以实现非常好的交流性能，具有10MHz带宽、8V/μs转换速率和100ns过载恢复时间，同时每个放大器仅消耗3mA的静态电流；TP258X系列在音频信号范围内实现了最佳的THD+N性能，是电机控制和音频放大的理想选择。

Features

-Supply Voltage:3V to 36V

-Differential Input Voltage Range to Supply Rail

-Input Rail to–VS,Rail to Rail Output

-Fast Response:10 MHz Bandwidth,8V/μs Slew Rate,

100ns Overload Recovery

-Low Offset Voltage:

±3mV Maximum at 25°C,

±3.5mV Maximum at-40°C to 85°C

±4mV Maximum at-40°C to 125°C

-Very Low THD+N:0.0007%at Gain=1,20kHz

-Excellent EMIRR:58dB at 900MHz

-2KV HBM,1KV CDM,150mA Latch Up

-–40°C to 125°C Operation Temperature Range

Applications

-Audio

-Sensor Interface

-Motor Control
