The JW1530 is a high efficiency low cost off-line constant voltage regulator for Buck and BuckBoost topology with 700V MOSFET integrated.

JW1530 can output 5V default voltage with few external components, which decreases the system cost. In light load condition, JW1530 operates in green mode, in which the inductor peak current and the switching frequency is lower than that of full load to improve the system efficiency and the reference voltage is decreased to ensure good load regulation.

JW1530 has multi-protection functions which largely enhance the safety and reliability of the system, including VDD under-voltage Lockout (UVLO), short circuit protection (SCP), pulse-bypulse current limit, over load protection (OLP) and over-temperature protection (OTP).

FEATURES


Ultra low system BOM cost


Integrated with 700V, low Rdson MOSFET


5V default output voltage


Peak current mode control


Built-in 30KHz Oscillator with frequency

Jittering


High efficiency over wide operating range


VDD UVLO


Short circuit protection


Pulse-by-pulse current limit


Over temperature protection


TO-92,SOT23-3 package

APPLICATIONS


Homeappliance


Standby power


Consumer electronics
