The JW1120 is a current mode monolithic buck LED driver. Operating with an input range of 4.5-20V, JW1120 delivers 2A of continuous output current with two integrated N-Channel MOSFETs. The internal synchronous power switches provide high efficiency without the use of an external Schottky diode. At light loads, the LED driver operates in low frequency to maintain high efficiency and low output ripple.

The JW1120 guarantees robustness with LED short protection, thermal protection, start-up current run-away protection, input under voltage lockout.

The JW1120 is available in 6-pin and 8-pin TSOT packages, which provide a compact solution with minimal external components.

FEATURES


4.5V to 20V operating input range

2A output current


Up to 94% efficiency


High efficiency (>85%) at light load


Fixed 1MHz Switching frequency


Input under voltage lockout


Start-up current run-away protection


LED short protection


Thermal protection


Available in TSOT23-6 and TSOT23-8

packages

APPLICATIONS


LED Driver
